Model ：4DY-720/12A-30/300A Series
1. Summary

Modle 4DY-720/12A-30/300A Series electric pressure testing pump ( here after called pump for short) is and equipment provided specially for testing water pressure of various pressure vessels, pipes ,valves, and etc., and for getting high pressure liquid in labs .This pump is specially designed in the light of the requirements of mater pressure test. During the initial stage of pressure testing, the pump can be quickly filled with liquid and its pressure booms thus shortening the testing time. The pump has a greater flow,when the pressure is over 1.6Mpa（this pressure can be lowered, the flow is automatically reduced in order that pressure testing can be carried out smoothly and slowly .Therefore at high pressure and low pressure the pump has two different flows, which can be automatically shifted .If  the outlet pressure of the pump is less than the rated one, the test of any water pressure can be carried out .

 2. Parameters

  The basic parameters are indicated as below table


Model

Rated outlet pressure
Mpa

 Flow  L/h

Dia。Of hp piunger
 mm

  Motor to be served

Overall dimensions
Lxhxw mm

Weight
 Kg

At high pressure

At low pressure

model

Kw

4DY-720/12

 12

720

2390

 36


Y132M-4



7.5

1020×590×1265


410


4DY-560/16

 16

560

2230

 32

4DY-350/25

 25

 320

2020

 25

4DY-220/40

 40

 220

1890

 20

4DY-150/48

 63

 150

1820

 16

4DY-110/100

 100

 110

1780

 14

4DY-75/130

 130

 75

1760

 12

4DY-50/160

 160

 50

 760

 10

4DY-35/200

 200

 35

 750

 9









4DY-30/300

 300

 28

 740

 8

 Working pressure of the low pressure water cylinders：≦1.6MPA
Number of cylinders：4
Plunger stroke：50mm
Pump speed：141  /min
